Ducati DARK 749 - Page 62

Caratteristiche tecniche
Specifications
sezione / section
C 3
32
A
B
C
D
E
F
G
H
L
M
N
P
749/749 DARK/749S Aggiornamento/Update - M.Y. 2006 - edizione/edition 00
Rear Shock Absorber
Screw securing shock absorber to swing arm 10x1.25 42* Grease B
Screw securing shock absorber to rocker arm 10x1.25 42* Grease B
Screw securing shock absorber reaction arm to rocker
arm
10x1.25 42* Grease B
Nut securing suspension rocker arm to frame 10x1.25 42* Grease B
Front and Rear Mudguards
Front mudguard screw 6x1 3 Lock 2
Screws securing number plate to silencer 6x1 5
Number plate holder screws 6x1 6
Bolt securing reflector support to number plate support 6x1 4
Footpegs and Levers
Front/rear footpeg mounting plate screw 8x1.25 24 Lock 2
Clutch slave cylinder screw 6x1 10 Lock 1
Nut securing UNIBALL to gear rod ...... 10
Screw securing gear change linkage adjuster 6x1 8
Gear pedal shaft 8x1.25 23 Lock 2
Footpeg guard screw 5x0.8 5 Lock 2
Front and Rear Wheels
Rear wheel nut 30x1.5 180* Grease B
Front wheel spindle nut 25x1.25 63* Grease B (apply to thread
under nut head and to
wheel spindle)
Fixings securing cush drive pins to sprocket ...... 55* Lock 5 (LH threads)
Chain ring nuts 10x1.25 46* Grease B
Front/rear brake disc screw 8x1.25 25* Lock 2
Fuel Tank
Fuel tank drain hose clamp nut 6x1 10
Tank filler cap screws 5x0.8 5
Fuel tank flange nuts 6x1 8
Fuel tank pipe clamp screw ...... 1,5
Fuel tank connector cover 4x0.7 1,6
Exhaust System
Central M8 screw securing silencer + heat shield to
subframe
8x1.25 24
M6 screw securing silencer + heat shield to subframe 6x1 10
Screw securing front footpeg and exhaust pipe guard 6x1 10 Lock 2
Nut securing rear wiring conduit to silencer 6x1 8
Nuts securing exhaust pipe to cylinder head 6x1 9
Stainless steel plugs to exhaust pipe retainers 1/8 gas 25
Screw securing exhaust pipe to frame 6x1 9
Screw securing heat shield to exhaust pipe 6x1 3
Seat
Seat lock ringnut ...... 5,5
Screw securing seat/fuel tank/tail guard assembly to
subframe
6x1 10
Seat mounting screw ...... 6
Nut securing seat to fuel tank 8x1.5 24
Part Thread (mm) Nm ±10% Tolerance Notes
