LH switch screw ...... 0,8
Coil / head nut 6x1
Voltage regulator / battery support screw 6x1 3
Keyswitch screw 6x1 10 * Tighten down the Lock 2
screw head until it fails
Key cover cap nut 6x1 8
Immobilizer antenna ...... ...... Assemble on assembly
line applying Loctite 11
between the antenna
and switch cover
Heat shield / battery support screws Self-tapping 1,3
Ground cable screw 6x1 8
Speed sensor screw 6x1 10
ECU screw 6x1 8
Front brake
Front brake calliper screw 10x1.5 43* Grease B
Front brake bleeder connector 6x1 12
Front/rear brake hose clamp 10x1 20
Front brake master cylinder / handlebar screw 6x1 9 1 (UP)-2-1 Sequence
Screw securing front brake line guide to steering yoke ...... 1,3
Rear brake
Rear brake calliper screw 8x1.25 25* Grease B
Rear brake master cylinder screw 6x1 10
Rear brake master cylinder bracket screw 10x1.5 43 Lock 5
Screw securing brake fluid reservoir to frame 6x1 2
Rear brake lever pin 10x1.5 29 Lock 2
Brake pedal adjuster screw ...... 2,3
Rear brake pedal light switch ...... 5
Rear brake control rod nut 6x1 7,5
Screw securing footpeg to brake lever ...... 12
Rear Swingarm
Chain sliding shoe screw 6x1 10 Lock 2
Swingarm pivot shaft screw 15x1.25 72*
Lower chain sliding shoe screw 6x1 10 Lock 2
Calliper plate pin 10x1.5 33* Lock 8
Chain tensioner slide ring nut ...... 5
Chain tensioner slider adjuster nuts for aluminium alloy
box-section swing arm
8x1.5 8
Screw securing plastic/carbon fibre chain cover for
aluminium alloy box-section swing arm
6x1 4 Lock 2
Screw securing rear brake pipe clip to box-section swing
arm
5x0.8 5
Self-shearing screw on box-section swing arm 6x1 9
Handlebars - Clutch Control
Handlebar screw 8x1 25*
Clutch master cylinder / handlebar screw 6x1 9
Clutch pipe connector 10x1 20
Clutch slave cylinder screw 6x1 10
Throttle control screw 6x1 10
