Caratteristiche tecniche
Specifications
sezione / section
C 3
36
A
B
C
D
E
F
G
H
L
M
N
P
749/749 DARK/749S Aggiornamento/Update - M.Y. 2006 - edizione/edition 00
Cylinder head nuts:
1 Apply GREASE C
2 Ist stage tightening to 15 Nm
3 2nd stage tightening to 30 Nm
(min.28 max.32)
4 Final stage tightening to 48 Nm
(min.28 max.32)
M 10x1.5
Connecting rod screws:
1 Apply GREASE B to thread
2 Tighten to 35 Nm at 50 rpm
3 2 second pause, then back off
through 360° a 30 rpm
4 Tighten to 20 Nm at 30 rpm
5 Tighten to 35 Nm at 10 rpm
6
7 Check torque: 70-103 Nm
M 10x1
Oil pump duct plug M 10x1.5 fully home with tool
15 13 17
LOCK 5 or THREE
BOND 1375B
Cylinder head studs M 10x1.5 25 23 26 LOCK 2 or THREE
BOND 1324
Pressure switch M 10x1 19 17 21
Reduction bush M 10x1 LOCK 5 or THREE
BOND 1375B
Spark plug M 10x1 15 13 17
Water pump cover plug M 10x1 20 18 22
Neutral light switch M 10x1.25 10 9 11
Clutch-side casing service cap M 10x1.5 15 13 17 LOCK 5 or THREE
BOND 1375B
Oil circuit plug - drain side M 10x1 15 13 17 LOCK 2 or THREE
BOND 1374
Crankshaft grub screws M 8x1.25 13 11 15 THREE BOND 1375B
Mobile tensioner pin M 8x1.25 26 23 29 LOCK 2 or THREE
BOND 1324
Fixed tensioner pin M 8x1.25 26 23 29 LOCK 2 or THREE
BOND 1324
Gearshift pawl bolt M 8x1.25 25 22 28
Gear stop lever screw M 8x1.25 18 16 20 LOCK 2 or THREE
BOND 1324
Oil pump screws M 8x1.25 26 23 29
Dry clutch housing screws M 8x1.25 35 33 37 LOCK 4
Crankcase screws:
1st stage
Final Stage
M 8x1.25
19
25
17
22
21
28
GREASE B
Rocker cover screws:
1st stage
Final stage
M 8x1.25
10
22,5
9
21
11
25
GREASE B
Crankcase drilled bolt M 8x1.25 20 18 22 GREASE B
Ground screw M 8x1.5 13 11 15
Tensioner eccentric nut M8x1.25 25 22 28 GREASE A
Screws for cylinder head side cover on timing side M 6x1 10 9 11 LOCK 2 or TB 1324
Clutch spring screws M 6x1 6 5 7
Part Thread (mm) Nm Min. Max. Notes
