Ducati DARK 749 - Page 67

Caratteristiche tecniche
Specifications
sezione / section
C 3
37
A
B
C
D
E
F
G
H
L
M
N
P
749/749 DARK/749S Aggiornamento/Update - M.Y. 2006 - edizione/edition 00
Stator cable clamp bracket screws M 6x1 10 9 11 LOCK 2 or THREE
BOND 1324
Intake and exhaust flange studs M 6x1 5 5 7 LOCK 2 or THREE
BOND 1324
Starter motor screws M 6x1 10 9 11 LOCK 2 or THREE
BOND 1324
Starter idle gear shaft screw M 6x1 10 9 11 LOCK 2 or THREE
BOND 1324
Coolant pump bearing stop screw M 6x1 10 9 11 LOCK 2 or THREE
BOND 1324
Generator stator bolts M 6x1 10 9 11 LOCK 2 or THREE
BOND 1324
Rotor / flywheel bolts M 6x1 13 11 15 LOCK 2 or THREE
BOND 1324
Gearbox bearing retaining plate screws M 6x1 10 9 11 LOCK 2 or THREE
BOND 1324
Coolant drain bolt on union M 6x1 8 7 8 LOCK 2 or THREE
BOND 1324
Fuel pump / intake manifold union M 6x1 2,5 2 3 LOCK 2 or THREE
BOND 1324
Bosch pick-up screws M 6x1 10 9 11
Fluid recovery tank bracket nut M 6x1 9 8 10
Spark plug cap screws M 6x1 10 9 11 LOCK 2 or THREE
BOND 1324
Battery support stud M 6x1 10 9 11 LOCK 2 or THREE
BOND 1324
Battery support lower stud M 6x1 10 9 11 LOCK 2 or THREE
BOND 1324
Cylinder-side cover screws M 6x1 10 9 11 LOCK 2 or THREE
BOND 1324
Cylinder head cover studs M 6x1 10 9 11 LOCK 5 or THREE
BOND 1375B
Driven pulley flange screws M 6x1 10 9 11
Cylinder coolant inlet union screw M 6x1 10 9 11 LOCK 2 or THREE
BOND 1324
Gearshift pawl screw M 6x1 10 8,5 9,5 LOCK 2 or THREE
BOND 1324
Cylinder heads/cylinders coolant cover screws M 6x1 6 6 8
Inspection cover screws M 6x1 4,5 4,5 6
Cylinder head coolant outlet union screw M 6x1 10 9 11
Rocker shaft cover screws M 6x1 10 9 11
Intake/exhaust valves cover screws M 6x1 10 9 11
Intake manifold nuts M 6x1 10 9 11
Crankcase screws M 6x1 9 8,5 9,5
Clutch cover screws M 6x1 9 8,5 9,5
Generator cover screws M 6x1 10 9 11
Cylinder head cover nut M 6x1 10 9 11
Intake manifold plug M 5x0.8 3 2 3
Clutch spring screws M 5x0.8 5 5 7 GREASE A
Part Thread (mm) Nm Min. Max. Notes
