Chapter 2 Troubleshooting
FIP-1.41 033-511: Communication Error
Step Check
Remedy
Yes No
Possible causative parts:
PWBA FAX (PL8.1.5)
PWBA ESS AIO (PL8.1.2)
1
Checking the telephone line connection.
Reconnect the telephone line connector.
Does the error still occur when faxing?
Go to step 2. End of work.
2
Checking the receiving side fax
Send the fax data to known good fax machine.
Does the error still occur when faxing?
Go to step 3.
END, check the
receiving side fax
machine.
3
Checking the firmware version.
Is the firmware the latest version?
Go to step 4.
Upgrade the
firmware, then go
to step 4.
4
Checking after replacing the PWBA FAX
Replace the PWBA FAX. (Refer to REP8.4.)
Does the error still occur when faxing?
Replace the KIT
PWBA ESS AIO.
(Refer to REP8.2.)
End of work.
