Fuji Xerox DocuPrint CM305 df - FIP-1.N2 Noise: During Standby

2 - 174
Chapter 2 Troubleshooting
FIP-1.N2 Noise: During Standby
Step Check
Remedy
Yes No
Possible causative parts:
FAN (PL8.2.8)
PWBA LVPS (PL8.2.12)
1
Checking the FAN.
Does the noise arise from the Fan?
Checked by [Digital Output] - [Fan Motor] in [IOT Diag] of
diagnosis.
Replace the
DUCT FAN ASSY
AIO. (Refer to
REP8.8.)
Replace the
PWBA LVPS
(Refer to REP8.9.)
