Chapter 5 Parts List
PL 9.1 Harness [List]
ITEM PARTS No. DESCRIPTION A.C
1 962K 87510 HARNESS ASSY ESS MG AIO (J10-J2001) 71K1
2 962K 87520 HARNESS ASSY ESS VIDEO MG AIO (J11-J2002) 71K2
3 962K 87541
(SCC) HARNESS ASSY LVPS MAIN MG AIO (J14,J15,P5041-
J141, J501, J502, J504) (REP 99.1.1)
71K3
4- -- -
5 962K 65240 (SCC) HARN ASSY HVPS AIO (J16-J161) (REP 99.1.1) 71K5
6 962K 87410 HARNESS ASSY HUM (J20-J201) 71K6
7 962K 87470
(SCC) HARNESS ASSY MAIN MOT MG AIO (J21-J211)
(REP 99.1.1)
71K7
8 962K 87490
(SCC) HARNESS ASSY SUB MOT MG AIO (J22-J221)
(REP 99.1.1)
71K8
9 - - HARNESS ASSY KSNR REGCL MG AIO (J26-J261,P262) 71K9
10 962K 87570 HARNESS ASSY ESS PER MG AIO (J40-J802) 71KB
11 962K 52000 HARN ASSY PHD XPRO (J42-J144,P422) 71KC
12 962K 85830 HARNESS ASSY A-OP-ESS (J403-P5301) 71KD
