Chapter 5 Parts List
PL12.2 250 Feeder (Option) (2/5) [List]
ITEM PARTS No. DESCRIPTION A.C
1 960K 54130 PWB ASSY FEED MG AIO 5844
2 962K 92800 HARNESS ASSY TRAY MOT (J422-J4221) 71N1
3- -- -
4- -- -
5- -- -
6 - - CLUTCH ASSY DRV [Same as PL3.1.1] 5842
7- -- -
8 - - SPRING FEED OUT [Same as PL3.1.15] 58C1
9 - - SPRING FEED IN [Same as PL3.1.14] 58C2
10 - - GEAR ASSY FEED (with 11,12) [Same as PL3.1.19] 58C3
11 - - GEAR FEED OUT [Same as PL3.1.16] 58C4
12 - - GEAR FEED IN [Same as PL3.1.17] 58C5
13 - - LEVER FEED [Same as PL3.1.13] 58C6
14 - - SPRING LEVER [Same as PL3.1.12] 58C7
15 - - SOLENOID FEED MSI [Same as PL3.1.11] 58C8
16 127K 58320 (SCC) MOTOR ASSY SUB (REP 99.1.1) 5841
17 807E 24010 GEAR IDLE 40Z 58C9
18 807E 24000 GEAR IDLE 86-20Z 58CB
19 - - PLATE ASSY IDLE 1 58CC
20 962K 68810
HARNESS ASSY TRAY COMP (J420,J421-P4201, J4202,
P4211, J4212)
71N2
21 - - COVER HARNESS CL 58CD
22 - - PLATE ASSY IDLER 2 58CE
23 - - GEAR IDLE 36Z 58CF
24 807E 23991 GEAR IDLE 28-20Z 58CG
25 - - GEAR IDLE 22-33Z 58CH
26 - - GEAR IDLE 25Z 58CJ
27 - - PLATE SUPPORT 58CK
99 604K 51900 KIT GEAR ASSY FDR SA (with 21-27) 58CL
To Next Page
