Fuji Xerox DocuPrint CM305 df Service Manual

2 - 91
Chapter 2 Troubleshooting
FIP-1.53 035-793: Digital Line Detection
Step Check
Remedy
Yes No
Possible causative parts:
PWBA FAX (PL8.1.5)
PWBA ESS AIO (PL8.1.2)
1
Checking the PSTN line.
Is the printer connected to the PSTN line?
Go to step 2.
Change to the
PBX line. Set the
[Line Type] of
[Fax setting] in the
[Admin Menu] to
the PBX.
2
Checking after replacing the PWBA FAX
Replace the PWBA FAX. (Refer to REP8.4.)
Does the error still occur when faxing?
Replace the KIT
PWBA ESS AIO.
(Refer to REP8.2.)
End of work.
