5 – 13
Chapter 5 Parts List
PL 4.1 Xerographics [List]
ITEM PARTS No. DESCRIPTION A.C
1 - - ROS ASSY 1310
2 - - SPRING ROS 13B1
3 019E 66470 HOLDER CRUM 4533
4 - - SPRING PHD 31B1
5 - - LEVER PHD 31B2
6 - - BLOCK STOPPER PHD D 31B3
7 - - BLOCK STOPPER PHD AD 31B4
8 122K 94041 LED ASSY ERASE 4421
9 - - SPRING TRACKING 71D1
10 - - SPRING CF 71D2
11 - - SPRING TR4 71D3
12 - - SPRING TR3 71D4
13 - - SPRING TR2 71D5
14 - - SPRING TR1 71D6
15 - - SPRING D4 71D7
16 - - SPRING D3 71D8
17 - - SPRING D2 71D9
18 - - SPRING D1 71DB
19 105K 24390 (SCC) PWBA HVPS (REP 4.5 , REP 99.1.1) 7320
20 - - - -
21 - - PHD ASSY 4510
22 962K 52060 (SCC) HARN ASSY ROS RE (J40-J411) (REP 99.1.1) 13B2
23 962K 52070 HARN ASSY ROS VIDEO (J41-J412) 13B3
97 675K 54241 KIT BLOCK PHD RIGHT (with 4,5,7x2) 13B5
98 675K 54251 KIT BLOCK PHD LEFT (with 4,5,6x2) 13B6
99 604K 65720 KIT ROS (with 1,2 × 2pcs w/screw) 13AA
To Next Page
