Fuji Xerox DocuPrint CM305 df - Diag. Mode Menu Tree

6 – 65
Chapter 6 General
6.4.3.7 Diag. mode menu tree
Menu Tree of the CE (Customer Engineer) Mode is as follows
Press the
key
Press the OK key
Press the
key
Press the STOP key
CE Mode
Printer Diag
ESS Diag All Test
EEPROM Test
FlashROM Test
DRAM Test
MAC+PHY Test
ASIC Test
Panel Test
Engine Test
USB Host Test
RTC Test
Engine Diag Sensor Test
Motor Test
Print Info Info Page
Print Settings
Installation Serial No.
HexDump
Print Service FullColor
B/W
Total
FullColor Backup
B/W Backup
Total Backup
FullColor Error
B/W Error
Tone Correction
Pixel Counter
Configuration
Print Counter
Dig
NVM Settings Edit NVM
SaveNVM to ESS
LoadNVM from ESS
Initialize Slave
