Fuji Xerox DocuPrint CM305 df Service Manual

2 - 117
Chapter 2 Troubleshooting
FIP-1.67 072-215: IOT Feeder Configuration Failure
Step Check
Remedy
Yes No
Possible causative parts:
HARNESS ASSY OPTION MG AIO (PL3.1.20)
PWBA MCU (PL8.3.6)
KIT FEEDER ASSY OPT MG AIO (PL12.1.99)
HARNESS ASSY TRAY (PL12.3.23)
1
Checking the Optional Feeder for installation.
Is the Optional Feeder installed correctly?
Go to step 3.
Reseat the
Optional Feeder,
then go to step 2.
2
Does the error still occur when the power is turned OFF and
ON?
Go to step 3. End of work.
3
Checking the connectors for connection.
Check the connections between the PWB ASSY FEED MG
AIO and PWBA MCU.
Are P/J27, P/J273, and P/J419 connected surely?
Go to step 5.
Reconnect the
connector(s) P/
J27, P/J273 and/
or P/J419 surely,
then go to step 4.
4
Does the error still occur when the power is turned OFF and
ON?
Go to step 5. End of work.
5
Checking the HARNESS ASSY TRAY for continuity.
Disconnect P/J419 from the PWB ASSY FEED MG AIO.
Disconnect P/J273 from the HARNESS ASSY OPTION MG
AIO.
Is each cable of P/J419 <=> P/J273 continuous?
Go to step 6.
Replace the
HARNESS ASSY
TRAY.
6
Checking the HARNESS ASSY OPTION MG AIO for
continuity.
Disconnect P/J27 from the PWBA MCU.
Disconnect P/J273 from the HARNESS ASSY TRAY.
Is each cable of P/J27 <=> P/J273 continuous?
Go to step 7.
Replace the
HARNESS ASSY
OPTION MG AIO.
7
Checking after replacing the KIT FEEDER ASSY OPT MG
AIO.
Replace the Replace the KIT FEEDER ASSY OPT MG AIO.
(Refer to REP11.1.)
Does the error still occur when the power is turned OFF and
ON?
Replace the KIT
PWBA MCU.
(Refer to
REP8.10.)
End of work.
