Chapter 5 Parts List
PL 3.2 Paper Feeder (2/2) [List]
ITEM PARTS No. DESCRIPTION A.C
1 - - CHUTE ASSY FDR REGI (with 2-16,20-33, 36) 50D1
2 - - SHAFÇs ASSY FEED 50D2
3 - - ROLL CORE MSI 50D3
4 059K 60140 ROLL ASSY FEED 5012
5 - - BEARING EARTH 50D4
6 120E 27831 ACTUATOR REGI OUT 50D5
7 809E 71020 SPRING REGI OUT 50D6
8 120E 32810 ACTUATOR REGI ROLL M 50D7
9 059K 60152 ROLL ASSY REGI 50D8
10 - - ROLL REGI METAL 50D9
11 120E 30270 ACTUATOR REGI IN 50DB
12 809E 70960 SPRING ACT REGI 50DC
13 930W 00113 SENSOR PHOTO 50DD
14 120E 27850 ACTUATOR SSI 50DE
15 809E 71030 SPRING ACT SSI 50DF
16 809E 70982 SPRING STP 50DG
17 - - STOPPER ACT 50DH
18 - - SPRING ACT NP 50DJ
19 - - ACTUATOR NO PAPER 50DK
20 - - BEARING M EARTH 50DL
21 - - BEARING EARTH REGI 50DM
22 - - GEAR REGI R 50DN
23 - - GEAR REGI M 50DP
24 - - SPRING REGI R MG 50DQ
25 - - PLATE EARTH REGI 50DR
26 - - CHUTE UP 50DS
27 054K 35890 CHUTE ASSY LOW (with 34,35) 50DT
28 674E 01840 BRACKET SNS 50DV
29 - - SPRING REGI L MG 50DW
30 - - BEARING M 50DX
31 - - BEARING R 50DY
32 120K 92294 ACTUATOR ASSY NO PAPER(with 17-19) 50E1
33 - - PLATE WEIGHT 50E2
34 - - CHUTE ASSY LOW SSI 50E3
35 - - CHUTE LOW CST 50E4
36 - - FILM CHUTE UP 50E5
97 604K 51890 KIT ACT REGI IN (with 11,12) 50E6
98 675K 65230 KIT ACT SSI (with 14,15) 50E7
97 675K 65241 KIT ACT NO PAPER (with 16,32) 50E8
