Chapter 2 Troubleshooting
FIP-1.83 091-912: PHD Tape Staying
Step Check
Remedy
Yes No
Possible causative parts:
PHD ASSY (PL4.1.21)
PWBA MCU (PL8.3.6)
1
Checking the sealing tapes of the PHD ASSY staying.
Turn off the power, and open the COVER ASSY FRONT.
Remove the PHD ASSY.
Has the sealing tapes (total eight sealing tapes) been pulled
out?
After checking, reseat the PHD ASSY correctly.
Go to step 3.
Pull the sealing
tapes out, then go
to step 2.
2
Does the error still occur when the power is turned OFF and
ON?
Go to step 3. End of work.
3
Checking after replacing the PHD ASSY.
Replace the PHD ASSY. (Refer to REP4.6.)
CAUTION: Be sure to pull eight sealing tapes out from a
new PHD ASSY before installation.
Does the error still occur when the power is turned OFF and
ON?
Replace the KIT
PWBA MCU.
(Refer to
REP8.10.)
End of work.
