5 – 33
Chapter 5 Parts List
PL11.1 Duplex (Option) (1/2) [List]
ITEM PARTS No. DESCRIPTION A.C
1 059K 72310 FEEDER ASSY DUP AIO STD (with 2-16,PL11.2) 52AA
2 - - CHUTE DUP IN 52B1
3 - - SPRING PINCH DUP 52B2
4 - - ROLL PINCH DUP 52B3
5 - - SPRING LATCH DUP 52B4
6 - - LATCH DUP 52B5
7 - - FOLLOWER LATCH DUP 52B6
8 - - HOLDER CHUTE DUP 52B7
9 - - SPRING CHUTE DUP 52B8
10 - - HOLDER HARNESS DUP 52B9
11 - - COVER CONNECT DUP 52BB
12 - - SPRING CONNECT DUP 52BC
13 - - HOLDER CONNECT DUP 52BD
14 - - HARNESS ASSY DUP STD MG AIO (J271-J601) 71M1
15 - - COVER PWBA DUP 52BE
16 960K 43081 (SCC) PWBA DUP (REP 99.1.1) 5261
98 604K 51850 KIT CHUTE DUP IN (with 2,3x4pcs,4x4pcs) 52BF
99 604K 51860 KIT HARNESS ASSY DUP (with 13,14) 71M2
To Next Page
