2 - 38
Chapter 2 Troubleshooting
FIP-1.2 005-110 / 005-121 / 005-124: PICKUP Jam / ADF Jam / Virtual Jam
Step Check
Remedy
Yes No
Possible causative parts:
PWBA ESS AIO (PL8.1.2)
ADF ASSY (PL10.1.3)
ROLL ASSY FEED & PAD ASSY SEPARATOR (PL10.1.5,
PL10.1.6)
1
Checking the document
Does the document meet the ADF SPEC?
Go to step 2.
Use the platen
mode or change
the paper type.
2
Checking the connector connection
Reseat the connector (P/J1003) on the PWBA ESS AIO.
Does the error still occur when copying?
Go to step 3. End of work.
3
Checking the ADF
Is the ADF closed against platen glass completely?
Go to step 4.
Close the ADF
completely.
4
Checking the paper feeding
Does the ADF feed the document?
Go to step 5. Go to step 7.
5
Checking the document path
Open the ADF Cover and check the document path.
Is there the foreign substance on the document path?
Remove the
foreign substance.
Go to step 6.
6
Checking after replacing the KIT ADF ASSY
Replace the KIT ADF ASSY. (Refer to REP9.1.)
Does the error still occur when copying?
Replace the KIT
PWBA ESS AIO.
(Refer to REP8.2.)
End of work.
7
Checking the ADF Feed Roller installation
Is the roller installed correctly?
Also are they not contaminated or damaged, and rotate
smoothly?
Replace the ADF
ASSY. (Refer to
REP9.1.)
Replace the ROLL
ASSY FEED &
PAD ASSY
SEPARATOR.
(Refer to REP9.2.)
To Next Page
