Chapter 5 Parts List
PL 3.1 Paper Feeder (1/2) [List]
ITEM PARTS No. DESCRIPTION A.C
1 121K 42520 (SCC) CLUTCH ASSY DRV (REP 3.1 , REP 99.1.1) 50C1
2 013E 30830 BEARING REGI 50C2
3- -- -
4 - - CHASSIS FDR R AIO 50C3
5 - - FOOT ASSY 50C4
6- -- -
7- -- -
8 - - CHASSIS FDR L AIO 50C5
9 - - BEARING 50C6
10 003E 73341 STOPPER CST 50C7
11 - - SOLENOID FEED MSI 50C8
12 - - SPRING LEVER 50C8
13 - - LEVER FEED 50CB
14 - - SPRING FEED IN 50CC
15 - - SPRING FEED OUT 50CD
16 - - GEAR FEED OUT 50CE
17 - - GEAR FEED IN 50CF
18 962K 87380
(SCC) HARNESS ASSY L SIDE MG AIO (J20,J23,J28-J201,
P231, J232, J233, J234, J281) (REP 99.1.1)
71C1
19 007K 15660 GEAR ASSY FEED (with 16,17) 50CG
20 - - HARNESS ASSY OPTION MG AIO (J27-P271,P273) 71C2
21 - - - -
22 - - - -
23 - - - -
24 - - - -
25 - - PLATE EARTH FDR R 50CH
26 - - - -
27 - - PLATE TIE 50CJ
28 - - PLATE EARTH FDR L 50CK
29 - - - -
30 - - - -
31 - - PLATE EARTH FDR 50CL
32 103E 42980 VARISTOR,S10K680E2 50CM
33 - - PLATE EARTH CST 50CN
97 - - KIT CLUTCH ASSY DRV (with 1,2) 50CP
98 059K 72260
FEEDER ASSY MG AIO DN (with 4,5,8-15,18-20,25,27,28,31-33,
PL3.2.1, PL8.1.10, PL9.1.6)
50CAA
99 604K 51880 KIT SOLENOID FEED SA (with 11-17) 50CQ
To Next Page
