Chapter 2 Troubleshooting
FIP-Multiple Feed
This multiple feed trouble occurs only when the paper is fed from the Paper Cassette.
Step Check
Remedy
Yes No
Possible causative parts:
HOLDER ASSY SEPARATOR (PL2.1.5)
ROLL ASSY FEED (PL3.2.4)
ROLL ASSY REGI (PL3.2.9)
ROLL REGI METAL (PL3.2.10)
1
Checking the using paper.
Does the using paper meet the specifications?
Go to step 3.
Use the paper that
meets the
specifications,
then go to step 2.
2 Does the multi feed still occur when printing? Go to step 3. End of work.
3
Checking paper condition.
Is the paper dry and recommended paper?
Go to step 5.
Replace the paper
with a new dry and
recommended
one, then go to
step 4.
4 Does the multi feed still occur when printing? Go to step 5. End of work.
5
Checking the ROLL ASSY FEED and HOLDER ASSY
SEPARATOR for rotation.
Does the ROLL ASSY FEED and HOLDER ASSY
SEPARATOR rotate smoothly and operate correctly?
End of work.
Replace the KIT
ROLL ASSY
FEED (Refer to
REP3.3.) and/or
KIT HOLDER
ASSY
SEPARATOR
(Refer to REP2.2.)
