6 – 2
Chapter 6 General
6.1.2 Electrical Properties
6.1.2.1 Power Source
Two types of power source as follows are available for this printer, which are selected according to the
specifications.
- 110V printer:...................... voltage: 100-127VAC ±10% (90 ~ 140V), frequency: 50/60Hz ± 3Hz
current capacity: 9A or less
- 220V printer:...................... voltage: 220-240VAC ±10% (198 ~ 264V), frequency: 50/60Hz ± 3Hz
current capacity: 5A or less
6.1.2.2 Power Consumption
Power consumption in each operation mode at rated voltage input
Measurement is performed with rated input in room temperature environment.
6.1.2.3 Rush Current
When the power switch is turned on, the inrush current shall be maximum 120A, 10ms (half cycle) or
less.
Operation mode Average (Wh/h)
Running mode (Ave.) 425 or less
Running mode (MAX.) 1100 or less
Standby mode 65 or less
Sleep mode 50 or less
Deep sleep mode 18.4 or less
