Fuji Xerox DocuPrint CM305 df - Mechanical Properties; Dimensions;Mass of Printer; Dimensions;Mass of 250 Feeder (Option); Dimensions;Mass of Consumables and Crus

6 – 3
Chapter 6 General
6.1.3 Mechanical Properties
6.1.3.1 Dimensions/Mass of Printer
*1: Depth of M/C is with paper tray.
*2: Mass of M/C is with CRU.
6.1.3.2 Dimensions/Mass of 250 Feeder (Option)
6.1.3.3 Dimensions/Mass of Consumables and CRUs
(1) PHD Unit
Width: 332mm
Depth: 138mm
Height: 196mm
Mass: 3.37kg
Reference: The PHD Unit has CRUM (CRU memory)
to record information.
Model Width(mm) Depth(mm) Height(mm) Mass(kg)
AIO N Model
430
544.2
*1
584.4
28.4
*2
AIO DN Model
29.6
*2
Width(mm) Depth(mm) Height(mm) Mass(kg)
419.2 518 106 4.5
MiA08003GA
MiA08013GA
Wsb08006KA
