Fuji Xerox DocuPrint CM305 df - PL10.1 Scanner Assy [List]

5 – 31
Chapter 5 Parts List
PL10.1 Scanner Assy [List]
ITEM PARTS No. DESCRIPTION A.C
1 062K 23300 (SCC) SCANNER ASSY (with 2,3,11) (REP 99.1.1) 11AA
2 - - HARN ASSY ADF(J1003-JADF1) 71L1
3 059K 72230 ADF ASSY (with 4-10,17) 22AA
4 848E 73310 COVER TOP ADF 22B1
5 059K 61851 ROLL ASSY FEED 2222
6 019K 10390 PAD ASSY SEPARATOR 2223
7 - - COVER ASSY REAR ADF 22B2
8 050K 63721 TRAY ASSY 22B3
9 - - COUNTER BALANCE L 2271
10 - - COUNTER BALANCE R 2271
11 062K 23310 IIT ASSY SUB 11B1
12 121E 22020 CORE FERR FFC 22B4
13 962K 83781 HARNESS ASSY FRONT USB (J2-J1301) 76B1
14 - - BRACKET ASSY USB (with 15,16) 76B2
15 - - PWB ASSY FRONT USB 76B3
16 960K 43081 BRACKET FRONT USB 76B4
17 050E 26440 TRAY EXTENT ADF 22B5
