4 - 1
Chapter 4 Disassembly / Assembly and Adjustments
4.1 Preface
Parts removal and replacement procedures are described in major 11 items which correspond to
classification of parts list.
*REP 1 COVERS
*REP 2 PAPER CASSETTE
*REP 3 PAPER FEEDER
*REP 4 XEROGRAPHICS
*REP 5 DISPENSER
*REP 6 TRANSFER & FUSING UNIT
*REP 7 DRIVE
*REP 8 ELECTRICAL
*REP 9 SCANNER ASSY
*REP 10 DUPLEX
*REP 11 OPTION FEEDER
When working on an item which is controlled as a spare part but the procedure
therefore is not described, observe carefully how the part is attached before
removing the item.
As a general rule, optional items are assumed to be removed from the
equipment. However, you may work with optional items attached if it does not
disturb your work.
Safety Critical Component (SCC)
Control of the safety of components that are designated Safety Critical Components shall conform
to Fuji Xerox Co. Ltd-stipulated rules and regulations on Safety Critical Components.
As to replacement of any component designated SCC, the complete component unit must be
replaced. It must never be disassembled or no individual internal parts of it must be replaced.
Installation of any part other than the ones designated by Fuji Xerox Co. Ltd. shall be strictly pro-
hibited because it cannot be guaranteed in quality and safety.
Important Information Stored Component (ISC)
Important Information Stored Components store customers' important information they have
entered after machine installation. When replacing Important Information Stored Components,
you must replace and discard them, following the procedure described in Chapter 4 Adjustments.
Take care never to let customer information leak out.
To Next Page
