Fuji Xerox DocuPrint CM305 df Service Manual

2 - 118
Chapter 2 Troubleshooting
FIP-1.68 072-216: Option Feeder Motor Failure
Step Check
Remedy
Yes No
Possible causative parts:
MOTOR ASSY SUB (PL12.2.16)
PWB ASSY FEED MG AIO (PL12.2.1)
HARNESS ASSY TRAY MOT (PL12.2.2)
KIT FEEDER ASSY OPT MG AIO (PL12.1.99)
1
Does the error still occur when the power is turned OFF and
ON?
Go to step 2. End of work.
2
Checking the connectors of the MOTOR ASSY SUB for
connection.
Check the connections between the PWB ASSY FEED MG
AIO and MOTOR ASSY SUB.
Are P/J422 and P/J4221 connected correctly?
Go to step 4.
Reconnect the
connector(s) P/
J422 and/or P/
J4221 correctly,
then go to step 3.
3
Does the error still occur when the power is turned OFF and
ON?
Go to step 4. End of work.
4
Checking the HARNESS ASSY TRAY MOT for continuity.
Disconnect J422 from the PWB ASSY FEED MG AIO.
Disconnect J4221 from the MOTOR ASSY SUB.
Is each cable of J422 <=> J4221 continuous?
Go to step 5.
Replace the
HARNESS ASSY
TRAY MOT.
5
Checking after resetting the MOTOR ASSY SUB.
Reseat the MOTOR ASSY SUB.
Does the error still occur when the power is turned OFF and
ON?
Replace the KIT
FEEDER ASSY
OPT MG AIO.
(Refer to
REP11.1.)
End of work.
