5 – 15
Chapter 5 Parts List
PL 5.1 Dispenser [List]
ITEM PARTS No. DESCRIPTION A.C
1 094K 92290 DISPENSER ASSY (with 2,9-11,14-16,25-27) 4020
2 - - FRAME ASSY MOT (with 3-8) 40B1
3 127K 51010 (SCC) MOTOR ASSY DISP (REP 99.1.1) 40B2
4 - - CONDUCTOR MOTOR 40B3
5 - - FRAME MOTOR 40B4
6 - - GEAR IDLER 40B5
7 - - GEAR IDLER AUG 40B6
8 - - GEAR IDLER AGI 40B7
9 110E 10200 SWITCH 40B8
10 - - HOUSING ASSY AUGER 40B9
11 - - FRAME ASSY DISP (with 12,13) 40BA
12 - - FRAME DISP 40BB
13 - - SEAL DISP AUG 40BC
14 - - CONNECTOR CRUM 40BD
15 - - SPRING DISP 40BE
16 - - JOINT ASSY DISP 40BF
17 604K 65770 HOLDER ASSY TCRU K 40BG
18 604K 65780 HOLDER ASSY TCRU C 40BH
19 604K 65790 HOLDER ASSY TCRU M 40BJ
20 604K 65800 HOLDER ASSY TCRU Y 40BK
21 - - TONER CARTRIDGE (K) 401K
22 - - TONER CARTRIDGE (C) 401C
23 - - TONER CARTRIDGE (M) 401M
24 - - TONER CARTRIDGE (Y) 401Y
25 - - HARN ASSY TNR MOT (J18,J19-J181,J182,J191,J192) 71E1
26 - - HARN ASSY TONER CRUM (J31-J311,J312,J313,J314) 71E2
27 962K 52150 HARN ASSY SIDE SW (J29-J291) 71E3
28 - - - -
29 - - LABEL HOLDER 40BL
To Next Page
