5 – 41
Chapter 5 Parts List
PL12.3 250 Feeder (Option) (3/5) [List]
ITEM PARTS No. DESCRIPTION A.C
1 - - SPRING EARTH OPT 58D1
2 - - PLATE REAR TOP 58D2
3- -- -
4- -- -
5- -- -
6- -- -
7 - - FOOT ASSY [Same as PL3.1.5] 58D3
8 - - PLATE EARTH PH [Same as PL3.1.6] 58D4
9 - - CHASSIS FDR R OPT 58D5
10 - - PLATE REAR BOTTOM M 58D6
11 - - PLATE FRONT BOTTOM 58D7
12 - - - -
13 - - CHASSIS FDR L OPT 58D8
14 - - PLATE EARTH FRONT BOTTOM 58D9
15 - - BRACKET SUP REGI 58DB
16 - - BEARING REGI [Same as PL3.1.2] 58DC
17 - - PLATE EARTH REAR BOTTOM 58DD
18 - - PLATE EARTH REAR TOP 58DE
19 848E 21900 COVER HARNESS DRAWER 58DF
20 - - - -
21 - - STOPPER CST [Same as PL3.1.10] 58DG
22 - - BEARING [Same as PL3.1.9] 58DH
23 962K 68800 HARNESS ASSY TRAY (J273-J419) 71P1
24 - - BRACKET CHASSIS FDR L AIO 58DK
25 - - BRACKET CHASSIS FDR R AIO 58DL
To Next Page
