6.3 Service Data
6.3.1 NVM Access
By operating the Control Panel, you can access the NVM (EEPROM in the IOT) to read/write data
there.
The following functions are available.
• Editing NVM data. Data at the addresses below can be edited.
• Saving NVM data into the Controller.
• Loading data saved in the Controller back into the NVM
• Printing out data saved in the Controller
Editing NVM
The following shows how the UI guides you to edit data.
Saving NVM data
To save NVM data into the Controller. Data at the NVM addresses below can be saved.
1000-17FF in total
Loading NVM data
To load data saved in the Controller into the management areas below.
1000-17FF
Printing NVM data
To print data saved in the Controller.
1) Select the menu shown at left and press the Set key.
2) The LCD displays what is shown at left.
Pressing the left/right arrow allows moving the cursor to the left/right.
Pressing the up/down arrow allows changing the value the cursor points
to. Changing the value at Address Area (Ad) allows reading and
displaying data on the right side of the equal sign (=).
3) Changing the data leads to deletion of the * mark, which shows the
current NVM value is changed.
Set data at a specific address is represented by leftmost 2 digits
displayed on the right side of the equal sign "=".
4) Pressing the Set key allows writing a new value in the NVM.
5) Pressing the Cancel key allows returning to the previous screen.
EditNVM
Ad0100=00000001*
EditNVM
Ad0100=00000001
EditNVM
Ad0100=00000000*
