Fuji Xerox DocuPrint CM305 df Service Manual

5 – 21
Chapter 5 Parts List
PL 8.1 Electrical & Frame AIO (1/4) [List]
ITEM PARTS No. DESCRIPTION A.C
1 962K 65360
(SCC) HARN ASSY INTERLOCK AIO (SW-J44) (REP 8.1 ,
REP 99.1.1)
31C1
2 960K 56250 (ISC) (SCC) PWBA ESS AIO (with 3) (REP 8.2 , REP 99.1.1) 76AA
3- -NVM ROM 76B1
4 133K 26620 MEMORY CARD (OPTION) 7640
5 960K 53600 (SCC) PWBA FAX (REP 8.4 , REP 99.1.1) 7652
6 - - CAP PLUG RUBBER 76B2
7 - - SHIELD ASSY ESS AIO (with 8,9) 31C2
8 - - SHIELD ESS AIO 31C3
9 - - COVER INNER 31C4
10 130E 93460 SENSOR HUM 71H1
11 - - - -
12 - - - -
