2 - 158
Chapter 2 Troubleshooting
16
Checking after replacing the TONER CARTRIDGE (Y, M, C
or K).
Replace the TONER CARTRIDGE (Y, M, C or K), and check
that the lock key is in the lock position. (Refer to REP5.5.)
Does the error still occur when the power is turned OFF and
ON?
Go to step 17. End of work.
17
Checking after replacing the PHD ASSY.
Replace the PHD ASSY. (Refer to REP4.6.)
Does the error still occur when the power is turned OFF and
ON?
Go to step 18. End of work.
18
Checking after resetting the TRANSFER ASSY.
Reseat the TRANSFER ASSY.
Does the error still occur when the power is turned OFF and
ON?
Replace the KIT
TRANSFER
ASSY. (Refer to
REP6.3.)
End of work.
Step Check
Remedy
Yes No
To Next Page
