2 - 165
Chapter 2 Troubleshooting
FIP-1.99 116-316 / 116-320: ESS DIMM Slot RAM R/W Check Fail / ESS DIMM Slot RAM
Error
Step Check
Remedy
Yes No
Possible causative parts:
PWBA ESS AIO (PL8.1.2)
MEMORY CARD (OPTION) (PL8.1.4)
1 Is the customer using the recommended memory card? Go to step 3.
Replace to the
recommended
memory card,then
go step 2.
2
Does the error still occur when the power is turned OFF and
ON?
Go to step 3. End of work.
3
Checking the MEMORY CARD (OPTION) installation.
Reseat the MEMORY CARD (OPTION).
Does the error still occur when turning on the power?
Go to step 4. End of work.
4
Checking after resetting the MEMORY CARD (OPTION).
Replace the MEMORY CARD. (Refer to REP8.3.)
Does the error still occur when turning on the power?
Replace the KIT
PWBA ESS AIO.
(Refer to REP8.2.)
End of work.
To Next Page
