3 - 41
Chapter 3 Image Quality Troubleshooting
7
Checking the printing.
Checked by [Test Print] - [Gradation] in diagnosis.
Is the image printed correctly?
Printing data is
incorrect,then
check the printing
data which the
problem
generated.
Go to step 8.
8
Checking after replacing the PHD ASSY.
Replace the PHD ASSY. (Refer to REP4.6.)
Does the error appear on the printed material when
printing?
Go to step 9. End of work.
9
Checking after replacing the TRANSFER ASSY.
Replace the KIT TRANSFER ASSY. (Refer to REP6.3.)
Does the error appear on the printed material when
printing?
Replace the KIT
ROS. (Refer to
REP4.1.)
End of work.
Step Check
Remedy
Yes No
To Next Page
