Fuji Xerox DocuPrint CM305 df Service Manual

3 - 44
Chapter 3 Image Quality Troubleshooting
11
Checking the ROLL ASSY REGI and ROLL ASSY METAL
for rotation.
Checked by [Digital Output] - [Main Motor] in [IOT Diag],
and then enter the [Digital Output] - [Regi Clutch] in [IOT
Diag].
Does the Roll Assy Regi and Roll Regi Metal rotate?
During this check, cheat the interlock switch (HARN ASSY
INTERLOCK AIO).
End of work.
Replace the ROLL
ASSY REGI and/
or ROLL REGI
METAL.
12
Checking after resetting the Paper Cassette.
Reseat the Paper Cassette.
Is the image printed correctly?
End of work. Go to step 13.
13
Checking after resetting the paper.
Reseat the paper in the Paper Cassette.
Is the image printed correctly?
End of work. Go to step 14.
14
Checking the side guides of the Paper Cassette.
Reset the side guides.
Is the image printed correctly?
End of work. Go to step 15.
15
Checking the paper path.
Are there any foreign substances on the paper path?
Remove the
foreign
substances, then
go to step 16.
Go to step 17.
16 Is the image printed correctly? End of work. Go to step 17.
17
Checking after resetting the HOLDER ASSY SEPARATOR.
Reseat the HOLDER ASSY SEPARATOR.
Is the image printed correctly?
End of work. Go to step 18.
18
Checking after replacing the HOLDER ASSY SEPARATOR.
Replace the KIT HOLDER ASSY SEPARATOR. (Refer to
REP2.2.)
Is the image printed correctly?
End of work. Go to step 19.
19
Checking after resetting the ROLL ASSY FEED.
Reseat the ROLL ASSY FEED.
Is the image printed correctly?
End of work.
Replace the KIT
ROLL ASSY
FEED. (Refer to
REP3.3.)
Step Check
Remedy
Yes No
