Fuji Xerox DocuPrint CM305 df Service Manual

4 - 8
Chapter 4 Disassembly / Assembly and Adjustments
[Replacement]
1) Mate the two hooks of the COVER
POLE OUT AIO with the holes of
the printer.
2) Mate the hole of the COVER POLE
OUT AIO with the boss of the
COVER TOP AIO.
3) Secure the COVER POLE OUT AIO
to the printer with the one screw
(silver, 6mm) and the one screw (sil-
ver, tap, 8mm).
