4 - 27
Chapter 4 Disassembly / Assembly and Adjustments
[Replacement]
1) Insert the boss of the COVER ASSY
ESS to the hole of the COVER SIDE
L AIO, attach the COVER ASSY
ESS to the COVER SIDE L AIO.
