4 - 30
Chapter 4 Disassembly / Assembly and Adjustments
[Replacement]
1) Attach the COVER ASSY SIDE R
AIO to the printer
2) Secure the three hooks of the
COVER ASSY SIDE R AIO to the
printer.
3) Secure the COVER ASSY SIDE R
AIO to the printer with the eight
screws (silver, tap, 8mm).
