4 - 140
Chapter 4 Disassembly / Assembly and Adjustments
[Replacement]
1) Engage the connecter (P/J141) of the
LED ASSY ERASE.
2) Attach the LED ASSY ERASE to the
printer.
3) Secure the LED ASSY ERASE to
the printer with two screws (silver,
tap, 8mm).
