4 - 170
Chapter 4 Disassembly / Assembly and Adjustments
[Replacement]
Described below is the replacement procedure common among the four TONER
CARTRIDGEs.
Check that the TONER CARTRIDGE is secured.
1) Shake the TONER CARTRIDGE
five or six times for the distributing
toner evenly.
2) Insert the TONER CARTRIDGE
into the HOLDER ASSY TCRU
slowly, attach it.
3) Close the HOLDER ASSY TCRU.
To Next Page
