4 - 216
Chapter 4 Disassembly / Assembly and Adjustments
[Replacement]
Use the wrist strap to protect the PWB from the electrostatic.
1) Fit the MEMORY CARD into the
socket by mating the notch of the
MEMORY CARD with the lug on
the socket.
2) Insert the MEMORY CARD to the
socket until it locks.
3) Close the COVER ASSY ESS.
To Next Page
