Fuji Xerox DocuPrint CM305 df Service Manual

4 - 219
Chapter 4 Disassembly / Assembly and Adjustments
[Replacement]
NOTE
Use the wrist strap to protect the PWB from the electrostatic.
1) Engage the connector (P/J801) of the
PWBA FAX to the PWBA ESS AIO.
2) Secure the PWBA FAX to the
printer with the two screws (silver,
6mm).
