Fuji Xerox DocuPrint CM305 df Service Manual

4 - 247
Chapter 4 Disassembly / Assembly and Adjustments
4) Replace the clamp that secure the
harness of the SWITCH ASSY
INLET MG AIO to the PLATE
ASSY DUCT, route the harness of
the SWITCH ASSY INLET MG AIO
through the hook of the CHASSIS
INLET.
5) Secure the grounding terminal of the
SWITCH ASSY INLET MG AIO with
the one screw (silver, with washer,
6mm).
