4 - 289
Chapter 4 Disassembly / Assembly and Adjustments
[Replacement]
1) Align the arrow on the FEEDER
ASSY DUP AIO STD with the one
on the COVER ASSY FRONT,
attach the FEEDER ASSY DUP
AIO STD.
2) Push the FEEDER ASSY DUP AIO
STD to secure it.
