4 - 308
Chapter 4 Disassembly / Assembly and Adjustments
[Replacement]
1) Fit the ROLL ASSY FEED to the
SHAFT ASSY FEED with the
groove of the ROLL ASSY FEED
facing upward, rotate the ROLL
ASSY FEED 180 degrees so that the
pin on the SHAFT ASSY FEED is
aligned with the groove on the
ROLL ASSY FEED.
To Next Page
