Fuji Xerox DocuPrint CM305 df - Page 586

4 - 310
Chapter 4 Disassembly / Assembly and Adjustments
4) Insert the CASSETTE ASSY 250 OPT MG AIO into the FEEDER ASSY OPT MG AIO.
3) Move the ROLL CORE MSI to the
right side, to secure the hook of the
ROLL CORE MSI with the groove of
the SHAFT ASSY FEED.
