Chapter 5 Parts List
PL12.4 250 Feeder (Option) (4/5) [List]
ITEM PARTS No. DESCRIPTION A.C
1 059K 72170 CHUTE ASSY TURN (with 2-13,16,20-27,29-33) 5830
2 - - SHAFT ASSY FEED [Same as PL3.2.2] 58E1
3 - - ROLL CORE MSI [Same as PL3.2.3] 58E2
4 059K 60140 ROLL ASSY FEED [Same as PL3.2.4] 5833
5 - - BEARING EARTH [Same as PL3.2.5] 58E3
6 - - ACTUATOR REGI OUT [Same as PL3.2.6] 58E4
7 - - SPRING REGI OUT [Same as PL3.2.7] 58E5
8 120E 27931 ACTUATOR REGI ROLL 58E6
9 - - ROLL ASSY REGI 58E7
10 - - ROLL REGI METAL [Same as PL3.2.10] 58E8
11 120E 27820 ACTUATOR REGI IN 58E9
12 - - SPRING ACT REGI [Same as PL3.2.12] 58EB
13 930W 00113 SENSOR PHOTO [Same as PL3.2.13] 58EC
14 - - - -
15 - - - -
16 - - SPRING STP [Same as PL3.2.16] 58ED
17 - - STOPPER ACT [Same as PL3.2.17] 58EE
18 - - SPRING ACT NP [Same as PL3.2.18] 58EF
19 - - ACTUATOR NO PAPER [Same as PL3.2.19] 58EG
20 - - BEARING M EARTH [Same as PL3.2.20] 58EH
21 - - BEARING EARTH REGI [Same as PL3.2.21] 58EJ
22 - - GEAR REGI R [Same as PL3.2.22] 58EK
23 - - GEAR REGI M [Same as PL3.2.23] 58EL
24 - - SPRING REGI R M 58EM
25 - - PLATE EARTH REGI [Same as PL3.2.25] 58EN
26 - - CHUTE UP [Same as PL3.2.26] 58EP
27 - - CHUTE LOW 58EQ
28 - - - -
29 - - SPRING REGI L M 58ER
30 - - BEARING M [Same as PL3.2.30] 58ES
31 - - BEARING R [Same as PL3.2.31] 58ET
32 - - ACTUATOR ASSY NO PAPER (with 17-19) [Same as PL3.2.32] 58EV
33 - - PLATE WEIGHT [Same as PL3.2.33] 58EW
98 675K 65220 KIT ACT REGI IN (with 11,12) 58EX
99 675K 65241 KIT ACT NO PAPER (with 16,32) 58EY
