Chapter 5 Parts List
PL12.5 250 Feeder (Option) (5/5) [List]
ITEM PARTS No. DESCRIPTION A.C
1 - - CASSETTE ASSY 250 OPT MG AIO (with 19,21) 5810
2 - - PLATE ASSY BOTTOM [Same as PL2.1.2] 58F1
3 - - SPRING N/F L [Same as PL2.1.3] 58F2
4 - - SPRING N/F R [Same as PL2.1.4] 58F3
5 - - HOLDER ASSY SEPARATOR [Same as PL2.1.5] 58F4
6 038E 36920 GUIDE SIDE L [Same as PL2.1.6] 58F5
7 - - GEAR PINION [Same as PL2.1.7] 58F6
8 - - GUIDE SIDE ASSY R [Same as PL2.1.8] 58F7
9- -- -
10 - - - -
11 - - - -
12 - - - -
13 - - - -
14 - - LATCH BOTTOM L [Same as PL2.1.14] 58F8
15 - - LATCH BOTTOM R [Same as PL2.1.15] 58F9
16 809E 72211 SPRING LATCH B [Same as PL2.1.16] 58FB
17 050K 61170 TRAY ASSY EXTENSION [Same as PL2.1.17] 58FC
18 - - HOUSING CASSETTE 250 [Same as PL2.1.18] 58FD
19 003K 87540 HANDLE ASSY CST OPT MG AIO 58FE
20 - - - -
21 - -
TRAY ASSY CST 250 AIO (with 2-8, 14-18, 25-27) [Same as
PL2.1.21]
58FF
22 032E 26410 GUIDE BOTTOM L [Same as PL2.1.22] 58FG
23 032E 26420 GUIDE BOTTOM R [Same as PL2.1.23] 58FH
24 019K 09240 PAD ASSY BOTTOM [Same as PL2.1.24] 58FJ
25 038K 18440 GUIDE ASSY END [Same as PL2.1.25] 58FK
26 003E 76750 LATCH HSG END [Same as PL2.1.26] 58FL
27 809E 72211 SPRING LATCH [Same as PL2.1.27] 58FM
28 - - TRAY ASSY EXT OWN (with 17,25-27) [Same as PL2.1.28] 58FN
99 675K 62840 KIT GUIDE SIDE (with 6-8) 58FP
To Next Page
