6 – 30
Chapter 6 General
(7) Protocol Control Time
When data error is not identified, protocol control time (Tm, Tn, Tu) is as follows:
- V.17, V.29, V.27ter
-V.34
(8) Throughput
Sending time is calculated in the following formula:
Sending time = Setup time + Tm + (N X Tp) + {(N-1) X Tn} + Tu (sec.)
(N: Send quantity, TP: Image transmission time)
Mode
Before
messages: Tm
Between
messages: Tn
After
messages: Tu
Total
Standard protocol 16.4 sec. or less 3.2 sec. or less 4.4 sec. or less 24.0 sec. or less
Mode
Before
messages: Tm
Between
messages: Tn
After
messages: Tu
Total
Standard protocol 9.9 sec. or less 1.0 sec. or less 0.9 sec. or less 11.8 sec. or less
