6 – 88
Chapter 6 General
- PANEL Test
Tests the LED, LCD, and buttons of the control panel.
This test checks input and output of the control panel.
When buttons are pressed in the manner shown in the following table, the test displays the corre-
sponding contents on the LED and LCD.
 Indicates left side square is the Ready LED, middle square is the Alarm LED and right side square is the
Power Save LED. STOP
Not lighting Lighting
- Engine Test
Communication test with the Engine.
Execute this test when the 024-371 error occurred.
Test result: NG(Go to FIP.) OK(Turn off/ on the main power.)
READ ROM Revision No
This test checks communication with the Engine. Then it reads the status
Register of the Engine to check whether commands can be exchanged with the
Engine.
It sends the following command to read the status register, and checks
whether the appropriate response returns.
Button LED LCD
 Displays “ UP ” on the LCD.
 Displays “ DOWN ” on the LCD.
 Displays “ LEFT ” on the LCD.
 Displays “ RIGHT ” on the LCD.
OK  Displays “ SET ” on the LCD.
MENU  Displays “ MENU ” on the LCD.
STOP  Displays “ CANCEL JOB” on the LCD.
POWER SAVE  Displays “POWER SAVE ” on the LCD.
pressed at the same
time
- (The test is completed) - (The test is completed)
