7 - 2
Chapter 7 Wiring Data
211 I-137
Connects DRIVE ASSY MAIN (Main Motor) and HARNESS ASSY MAIN
MOT MG AIO
221 H-137
Connects DRIVE ASSY SUB (Sub Motor) and HARNESS ASSY SUB
MOT MG AIO
231 D-126
Connects FEEDER ASSY MG AIO (Feed Solenoid) and HARNESS ASSY
L SIDE MG AIO
232 F-126
Connects FEEDER ASSY MG AIO (REGI Sensor) and HARNESS ASSY
L SIDE MG AIO
233 G-126
Connects FEEDER ASSY MG AIO (SSI No Paper Sensor) and HARNESS
ASSY L SIDE MG AIO
234 G-125
Connects FEEDER ASSY MG AIO (Tray No Paper Sensor) and
HARNESS ASSY L SIDE MG AIO
241 G-139
Connects DRIVE ASSY PH (Color Mode Switching solenoid) and
HARNESS ASSY KSOL MG AIO
261 H-138
Connects DRIVE ASSY PH (Color Mode Switching Sensor) and
HARNESS ASSY KSNR REGCL MG AIO
262 I-138
Connects CLUTCH ASSY DRV and HARNESS ASSY KSNR REGCL MG
AIO
271 H-111
Connects FEEDER ASSY DUP AIO STD (HARNESS ASSY DUP STD
MG AIO) and HARNESS ASSY OPTION MG AIO (Optional Duplex Only)
273 H-140
Connects HARNESS ASSY OPTION MG AIO and 250 OPTION FEEDER
MG AIO (HARNESS ASSY TRAY) (Optional Duplex Only)
273 H-140
Connects HARNESS ASSY OPTION D-LESS MG AIO and 250 OPTION
FEEDER MG AIO (HARNESS ASSY TRAY) (Optional Duplex Only)
281 C-109
Connects TRANSFER ASSY (Harness Assy CTD SNR2) and HARNESS
ASSY L SIDE MG AIO
291 G-108
Connects DISPENSER ASSY (Side Cover Switch) and HARNESS ASSY
SIDE SW
311 G-110
Connects DISPENSER ASSY (Connector CRUM Y) and HARNESS
ASSY TONER CRUM
312 G-110
Connects DISPENSER ASSY (Connector CRUM M) and HARNESS
ASSY TONER CRUM
313 G-109
Connects DISPENSER ASSY (Connector CRUM C) and HARNESS
ASSY TONER CRUM
314 G-109
Connects DISPENSER ASSY (Connector CRUM K) and HARNESS
ASSY TONER CRUM
403 G-137
Connects PWBA ESS AIO and HARNESS ASSY A-OP-ESS
411 D-123
Connects ROS ASSY and HARNESS ASSY ROS RE
412 E-124
Connects ROS ASSY and HARNESS ASSY ROS VIDEO
422 H-150
Connects PHD ASSY ( Eeprom PHD) and HARNESS ASSY PHD XPRO
501 D-143
Connects PWBA LVPS and HARNESS ASSY LVPS MAIN MG AIO
502 D-143
Connects PWBA LVPS and HARNESS ASSY LVPS MAIN MG AIO
503 D-143
Connects PWBA LVPS and FAN
504 D-143
Connects PWBA LVPS and HARNESS ASSY LVPS MAIN MG AIO
801 F-139
Connects PWBA ESS AIO and PWBA FAX
802 G-136
Connects PWBA ESS AIO and HARNESS ASSY ESS PER MG AIO
1001 F-136
Connects PWBA ESS AIO and SCANNER ASSY (PCB CCD)
1002 G-136
Connects PWBA ESS AIO and SCANNER ASSY (Scanner Motor)
1003 G-136
Connects PWBA ESS AIO and SCANNER ASSY (ADF Assy)
1301 F-137
Connect
s PWBA ESS AIO and HA
RNESS ASSY FRONT USB
P/J Coordiates Remarks
To Next Page
