7 - 31
Chapter 7 Wiring Data
Signal line name Description
Y DISPENSE MOT A
Y DISPENSE MOT B
Y DISPENSE MOT XA
Y DISPENSE MOT XB
Drive control signal of the DISPENSE MOTOR (Y)
M DISPENSE MOT A
M DISPENSE MOT B
M DISPENSE MOT XA
M DISPENSE MOT XB
Drive control signal of the DISPENSE MOTOR (M)
C DISPENSE MOT A
C DISPENSE MOT B
C DISPENSE MOT XA
C DISPENSE MOT XB
Drive control signal of the DISPENSE MOTOR (C)
K DISPENSE MOT A
K DISPENSE MOT B
K DISPENSE MOT XA
K DISPENSE MOT XB
Drive control signal of the DISPENSE MOTOR (K)
DATA Y IN
CLK Y OUT
Control signal of the CONNECTOR CRUM (Y)
DATA M IN
CLK M OUT
Control signal of the CONNECTOR CRUM (M)
DATA C IN
CLK C OUT
Control signal of the CONNECTOR CRUM (C)
DATA K IN
CLK K OUT
Control signal of the CONNECTOR CRUM (K)
To Next Page
