Fuji Xerox DocuPrint CM305 df Service Manual

7 - 38
Chapter 7 Wiring Data
7.5.2.11 SCANNER ASSY (IIT)
PWBA ESS AIO
PL8.1.2
PWBA CCD
P/J1001 CON2
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
CON1
1
2
12
+24V DC
NC
SG
LED_ON
A-SG
CCD_12V
AFE3.3V
HOME SENS
DRIVER_5V
SG
xAFE RST
SH_R
AFESDIO
AFESCLK
xAFE_SEN
RXIN0-
RXIN0+
SG
RXIN1-
RXIN1+
SG
RXIN2-
RXIN2+
SG
RXINCLK-
RXINCLK+
SG
LVDSCLK+
LVDSCLK-
A-SG
IIT ASSY SUB
PL10.1.11
MiA07015KA
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
PWB ASSY FRONT USB
PL11.1.15
HARNESS ASSY FRONT USB
PL10.1.13
P/J1301 P/J1 J2
1
2
3
4
5
+5V DC
SG
D+
D-
+5VDC
1
2
3
4
5
5
4
3
2
1
P/J1002
1
2
3
4
SCAN MOT B
SCAN MOT /A
SCAN MOT A
SCAN MOT /B
SCANNER MOTOR
M
LAMP
INVERTER
LAMP
