Fuji Xerox DocuPrint CM305 df Service Manual

7 - 40
Chapter 7 Wiring Data
7.5.2.12 250 FEEDER
PWBA MCU
PL8.3.6
P/J27
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
P/J273
HARN ASSY TRAY
PL12.3.23
HARN ASSY OPTION AIO
PL3.1.20
P/J419
10
9
8
7
6
5
4
3
2
1
1
2
3
4
5
6
7
8
9
10
1
2
3
4
5
6
7
8
9
10
3
4
5
P/J421
SG
SG
SG
I/L +24VDC
I/L +24VDC
+3.3VDC
TRY SNS
Rxd
Txd
SG
PWBA FEED H
HARN ASSY TRAY COMP
PL12.2.20
HARN ASSY TRAY MOT
PL12.2.2
HARN ASSY TRAY COMP
PL12.2.20
PL12.2.1
P/J422 P/J4221
1
2
3
4
6
5
4
3
5
6
2
1
MOTOR ASSY
SUB
PL12.2.16
M
3
2
1
PULL UP +3.3VDC
SG
PAPER EMPTY SENSED (L) +3.3VDC
CST2 NO PAPER
SENSOR
PL12.4.13
FEED MOT ON/OFF
FEED MOT ALARM
FEED MOT CLK
FEED MOT CHANGE
SG
I/L +24VDC
P/J4212
3
2
1
1
2
3
4
5
6
3
2
1
SG
PAPER FEED SENSED (L) +3.3VDC
3.3V
PAPER PATH
SENSOR
PL12.4.13
P/J4200
3
2
1
1
2
3
I/L +24VDC
TURN CL ON (L) +24VDC
P/J4201P/J420
2
1
1
2
1
3
CLUTCH ASSY
DRV
PL12.2.6
I/L +24VDC
FEED CL ON (L) +24VDC
P/J4211
2
1
1
2
1
2
SOLENOID FEED
MSI
PL12.2.15
MiA07012KA
INTERLOCK
+24VDC
INTERLOCK
+24VDC
INTERLOCK
+24VDC
INTERLOCK
+24VDC
+3.3VDC
INTERLOCK
+24VDC
+3.3VDC
+3.3VDC
+3.3VDC
*CN2
*CN1
* The CN1 and CN2 are
printed on the board.
